Low Fin Seamless Copper Alloy Tube C10200 B75 12.7×1.2mm Annealed Finish

Brand Name : Torich

Model Number : C10200 B75

Certification : ISO 9001 ISO14001 TS16949

Place of Origin : China

MOQ : 200 pcs

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20000 Ton per Year

Delivery Time : 30-45 days after order confirmed

Packaging Details : In plywood case, In wooden box.

Characteristic : Low Fin Tube

Material : C10200, C11000 etc

Production Method : Seamless

Package : In bundles or as per requests

Finish : Annealed

Length : 1-12m

Type : Copper Low Fin Tube

MTC : EN10204.3.1

Contact Now

Products Description:

for Heat Exchanger Seamless Copper Low Fin Tube C10200 B75

Quick Detail:

Low-finned tubes are a reliable solution for controlling the temperature of gases and liquids, or for evaporating and condensing refrigerants. Thanks to their larger heat transfer surface area, they offer considerable potential to save in terms of materials and fill volumes.

Size:

Low Fin Seamless Copper Alloy Tube C10200 B75 12.7×1.2mm Annealed Finish

Plain tube (mm) Finned section dimensions (mm) Ratio De
D×t Tp dd dr di η mm
19×2 0.8 18.8 17 134 2.8 17.9
19×2 1 18.8 16.8 13.4 2.5 17.8
19×2 1.25 18.8 16.6 13 2.2 17.8
19×2 1.5 18.8 16.6 13 2 17.7
19×2 2 18.8 16.4 13 1.7 17.5
25×2.5 0.8 24.8 23 18.8 2.8 23.9
25×2.5 1 24.8 22.6 18.8 2.75 23.7
25×2.5 1.25 24.8 22.3 18 2.5 23.6
25×2.5 1.5 24.8 22.3 18 2.2 23.5
25×2.5 2 24.8 22 18 1.8 23.4
25×2.5 2.5 24.8 22 18 1.6 23.3
D------Outside diameter of plain end section
Dof----Diameter of top fins
Dr-----Root diameter of finned section
Di-----Inside diameter of finned section
T------Wall thickness of plain end section
Tp-----Fin pitch
De----Equivalent diameter of finned tube
L------Plain tube end length

Applications: Heat Exchanger Tube

The Benefits:

1. Offers 2.5-3 times the external surface area of bare tube

2. Enhanced heat exchanger efficiency means less tube is required to accomplish the same heat transfer as a bare tube

3. Low finned tube can increase the performance of an existing exchanger without the difficult and expensive task of building new shells etc

4. Reduced space and weight can be extremely valuable in offshore production or high elevation distillation columns. Low finned technology can transform large shell and tube exchangers into compact heat exchangers

Production Steel Tube:

Low Fin Seamless Copper Alloy Tube C10200 B75 12.7×1.2mm Annealed Finish

Low Fin Seamless Copper Alloy Tube C10200 B75 12.7×1.2mm Annealed Finish

Application:

Low Fin Seamless Copper Alloy Tube C10200 B75 12.7×1.2mm Annealed Finish
